Agricultural Machinery

Statical Fog

Statical Fog

Features

Improved design of electrostatic pesticide fogger

・Uniform dispersion
The pesticide adhesion to the back of leaves is improved.

・Economical
Spraying on crops is effective, economical and environmentally friendly due to less fall loss of pesticide.

Model Unit AES-03B-2
Dry Weight kg 1.2
Static Method   Induction Static Electricity
Number of Head   3
Flow ℓ/min 2.3~4.0(Disc D1.0)
Pressure MPa 1.0~3.0
Power Source   AA×4
Attached Disc   DISC D1.0
(DISC D0.7 IS OPTIONAL)

It runs with 4 AA Alkali batteries under Economy Mode for 15 hours and Turbo Mode for 8 hours.

Using time may fluctuate by the performance of the battery.

Chidori Type Statical Fog

Chidori Type Statical Fog

Features

Improved design of original electrostatic technology by downsizing the electrode. Ideal for pest control of standing crops such as cucumbers, eggplants and tomatoes. 4 heads reduces the amount of time and energy for application.

Model Unit AES-04B-2
Dry Weight kg 1.5
Static Method   Induction Static Electricity
Number of Head   4(Nozzle pitch 17cm)
Flow ℓ/min 3.1~5.3(Disc D1.0)
Pressure MPa 1.0~3.0
Power Source   AA×4
Attached Disc   DISC D1.0
(DISC D0.7 IS OPTIONAL)

It runs with 4 AA Alkali batteries under Economy Mode for 15 hours and Turbo Mode for 8 hours.

Using time may fluctuate by the performance of the battery.

Suzuran Type Statical Fog

Suzuran Type Statical Fog

Features

Improved design of the original electrostatic technology by downsizing the electrode. Nozzle lances are adjustable both vertically or horizontally so useable for both standing crops, such as cucumbers, tomatoes, eggplants, etc., and flat crops, such as watermelons, strawberries, cabbages, etc.

Model Unit AES-05B-2
Dry Weight kg 1.9
Static Method   Induction Static Electricity
Number of Head   5(Nozzle pitch 23cm)
Flow ℓ/min 3.8~6.6(Disc D1.0)
Pressure MPa 1.0~3.0
Power Source   AA×4
Attached Disc   DISC D1.0
(DISC D0.7 IS OPTIONAL)

It runs with 4 AA Alkali batteries under Economy Mode for 15 hours and Turbo Mode for 8 hours.

Using time may fluctuate by the performance of the battery.

Statical Fog with the cart

Statical Fog with the cart

Features

Improved design of the original electrostatic technology by downsizing the electrode.
Nozzle lances are adjustable both vertically or horizontally so useable for both standing crops, such as cucumbers, tomatoes, eggplants, etc., and flat crops, such as watermelons, strawberries, cabbages, etc.

Model Unit AES-10SBT-2 AES-10BT-2
Dry Weight kg 10 10
Static Method   Induction Static Electricity Induction Static Electricity
Number of Head   10(Nozzle pitch 25cm) 10(Nozzle pitch 30cm)
Flow ℓ/min 4.9~8.6(Disc D0.7) 4.9~8.6(Disc D0.7)
Pressure MPa 1.0~3.0 1.0~3.0
Power Source   AA×4 AA×4
Attached Disc   DISC D0.7
(DISC D1.0 IS OPTIONAL)
DISC D0.7
(DISC D1.0 IS OPTIONAL)

It runs with 4 AA Alkali batteries under Economy Mode for 15 hours and Turbo Mode for 8 hours.

Using time may fluctuate by the performance of the battery.
